Fein Magforce KBC 36 240V Compact Core Drilling Machine
Extremely small and light for working in tight and difficult-to-reach spots – including vertically and overhead – thanks to height of 169 mm, a length of 290 mm and a weight of 8.5 kg.
- Extremely low wear and long-life tool design with spindle sleeve feed without clearance for accurate drilling results in tough use in industry and manual trades.
- Very powerful and maintenance-free brushless 1200 W high-power motor with high speed stability for continuously fast work progress as well as forward / reverse running and electronic speed setting for all drilling applications, such as core drilling, twist drilling and tapping and countersinking.
- High gearbox positioning for optimum view of the drilling point.
- Large installation space under the drill spindle with a stroke range of 46 mm.
- Space-saving operation on both sides with ratchet.
- Combined drive shaft, 1/2” square and 8 mm hexagon socket.
- Intuitive operating concept avoids mix-ups and can be clearly seen by the user.
- Convenient magnetic holding force display.
- Tilt sensor stops the drill motor when the tool slips or tilts.
- Integrated handle.
- Speed saving "memory function".
- Personal safety switch.
- Slot for 5 mm hexagon socket wrench on the tool itself.
Features:
- Magnetic holding force display
- Reversible rotation
- Variable speed control
- Memory function
- Speed-controlled electronics (tacho)
- Tilt sensor
Specifications
- HM core drill max. ø (mm) 36
- HSS core drill max. ø (mm) 36
- Core drill drilling depth max. (mm) 35
- Twist drilling max. ø (mm) 16
- Tapping max. ø (M) 12
- Lowering max. ø (mm) 32
- Engine type Brushless
- Power consumption (W) 1.200
- Power output (W) 680
- Idle speed (1/min) 130 – 660
- Load speed (1/min) 130 – 610
- Core drill holder 3/4 in Weldon
- Hub (mm) 46
- Magnet holding power (N) 10.000
- Magnetic base dimensions (mm) 175 x 80 x 34
- Cable with plug (m) 3
- Overall height / overall length (mm) 169 x 290
- Square measure (mm) 40
- Weight according to EPTA (kg) 8,5
Supplied with:
- 1 x 1/2” ratchet
- 1 x 1/2” socket wrench extension
- 1 x coolant pump
- 1 lashing strap
- 1 swarf hook
- 1 x 82 mm centring pin
- 1 contact guard
- 1 additional handle
- 1 x 5 mm hexagon socket wrench
- 1 x 5 mm hexagon socket wrench with T-handle
- 1 case
